(FOR HIGH PRESSURE BOILERS)
SPECIFICATIONS
Material | ASTM A351 Gr Cf8 |
End Connections | Screwed BSPT 11 TPI |
Manufacturing Standard | As per IBR 1950 cl 331-334 |
Testing Standard | As per IBR 1950 cl 290 a |
Certification | IBR approved |
Sizes | ½ inch -1 inch |
TYPES
Size (inches) | Pressure (Kg/Cm 2) | Melting Temperature |
1 | 21 | 300 |
1 | 27.5 | 313 |
3/4 | 21 | 300 |
3/4 | 27.5 | 313 |
3/4 | 32 | 321 |
1/2 | 21 | 300 |
1/2 | 27.5 | 313 |
1/2 | 32 | 321 |
1/2 | 35 | 326 |
